Backhoe Chain Saw

The Backhoe chain saw consists of two parts: the chain blade cutting system and the wheeled loader. Its main purpose is to divide large blocks of raw materials and cut strip ore belts in mines.

This machine is powered by the diesel engine of the wheel loader itself and can work independently without the need for an external power source.

The mining operators work in a sealed cab and enjoy friendly working condition

The machine moves quickly, is easy to operate, and has high efficiency.

Product parameters


Model LZ-CS3400
Max Cutting Depth (m) 3.4
Kerf Width (mm) 40
Vertical Stroke of the Blade Arm (m)
3.0
Horizontal Stroke of the Blade Arm (m)
2.0
Swing Arm Angle 90°
Weight of Cutting Unit (kg) 4500
Max Climbing Slope 21°
Total Weight (kg) 12500
Total Power (kW) 75
Emission Standard
EU Stage V
